Features:

• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden drop in rotation speed (e.g. kick-back)
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing/production applications
• LED charge level indicator displays approximate remaining battery power
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Electronic current limiter protects motor from accidental overload
• Electric brake stops wheel or disc 3-5 seconds after switch is released for increased operator safety
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced performance, battery cycle life and overall battery life
• Integrated dust screens act as additional protection against dust, dirt and debris
• Slim, ergonomic soft rubber grip design for vibration absorption and comfortable operation

Specifications:

Type: Brushless
Series: LXT®
Bare Tool/Kit: Tool
Tool Type: Grinder
Wheel Diameter: 5 in
Spindle Thread Size: 5/8 in-11 UNC
Arbor Hole Size: 7/8 in
Wheel Type: Depressed Center
Voltage Rating: 40 V
Speed Rating: 8500 rpm
Vibration Level: 6.5 m/sq-s
Switch Type: Thumb
Sound Level: 81 dBA
Overall Length: 16-1/8 in
Includes: D-20797 5 in Depressed Centre Wheel, 347480-2 Wheel Cover, 158237-4 Side Handle, 782424-9 Lock Nut Wrench 28, 224448-4 Inner Flange, 224568-4) 5/8-45 ock Nut
